Monocrystalline panel
8.5W / 5V solar input for the solar-powered version.
Product overview
CPD-9208 is a solar lawn light from E-Able Power, combining a 8.5W solar panel, 3.2V / 12000mAh battery and 3030 chip output in a weather-protected IP65 housing.
The source-pack specification documents 320 mm × 150 mm × H800 – 1000 mm. It is designed for ground-level installation in garden beds, landscape borders and courtyard pathways.

8.5W / 5V solar input for the solar-powered version.
3.2V / 12000mAh battery configuration from the supplied specification.
IP65 rated construction for outdoor use.
3030 chip source with 3000K – 6500K colour temperature range.
| Solar & electrical | |
| Solar panel | 8.5W / 5V |
| Battery | 3.2V / 12000mAh |
| Rated power | 8.5W |
| Input voltage | DC 3.2V |
| Working time | 12 hrs (3 – 5 rainy days) |
| Optical performance | |
| Light source | 3030 chip |
| LED quantity | 3030 chip |
| Colour temperature | 3000K – 6500K |
| Luminous flux | 1386.68 lm (3000K) / 1420.45 lm (6500K) |
| Colour rendering | >80 |
| Beam angle | 180° |
| Construction & dimensions | |
| Material | Die-cast aluminum + tempered glass |
| Lamp colour | Black; other colours can be customized |
| Net weight | 5.18 / 5.85 kg |
| Size | 320 mm × 150 mm × H800 – 1000 mm |
| Installation | Ground-mount lawn light |
| Operating environment | |
| Waterproof level | IP65 |
| Operating temperature | -25°C – 50°C |
| Working humidity | 10% – 90% |






The CPD-9208 comes in 320 mm × 150 mm × H800 – 1000 mm.
It runs on a 3.2V / 12000mAh battery and provides 12 hrs (3 – 5 rainy days) of working time.
Yes. It is built from Die-cast aluminum + tempered glass and rated IP65 for outdoor exposure.
It offers 3000K – 6500K with roughly 1386.68 lm (3000K) / 1420.45 lm (6500K) luminous flux.
It is designed for ground-level landscape installation and weighs 5.18 / 5.85 kg.
A 8.5W / 5V monocrystalline solar panel charges the on-board battery.
Yes — configuration and colour options can be adapted. Contact us with your site and lighting requirements to review a CPD-9208 configuration.
Specifications are nominal and may change without notice; the contractual revision is the one confirmed in the order acknowledgement.
Project support
Share the layout, installation height and preferred colour temperature. Our team can help review a suitable CPD-9208 configuration.
