View Product| E-ABLE POWER — PRODUCT DATASHEET COMMERCIAL ENERGY STORAGE SOLUTIONS | HIGH-VOLTAGE DC RACK3-STACK / 241kWhFULLY CONFIGURABLE |
Key Specifications at a Glance
| Product Type | High-Voltage DC Battery Rack (Indoor) | Architecture | 3-Column Stack — Up to 45 Modules per Rack |
| Max Energy | 241 kWh per Rack (15 Modules/Column) | Battery Cells | Grade A LFP — 3.2V / 314Ah Prismatic |
| Cycle Life | 6,000+ at 25°C, 0.5C, 90% DOD | DC Voltage | Configurable up to 768Vdc+ per Rack |
| Charge / Discharge | 157A Continuous / 314A Peak | Communication | CAN 2.0 / RS485 / RS232 |
| BMS | 3-Level — Cell / Column / Rack | Module Weight | 125 kg per Module |
| Ingress Protection | IP20 — Indoor Rack Installation | Warranty | 5 Years (Scalable to 10 Years) |
Key Industrial Features
Ultimate Cycle LongevityGrade A 314Ah LFP cells deliver 6,000+ cycles at 90% DOD — 15+ years of daily operation. LFP thermal stability (>270 °C) and zero-cobalt chemistry provide the lowest TCO for large-scale stationary storage. | 3-Stack High-Density DesignPatented 3-column architecture packs 45 modules (241kWh) into a single rack footprint — roughly 2–3× the energy density of conventional single-column racks. Multiple racks parallel for multi-MWh installations. | Flexible High-Voltage OutputCustom series/parallel module configuration achieves target DC bus voltage up to 768Vdc+ — enabling direct DC coupling with commercial inverters without intermediate DC/DC stages, reducing cost and efficiency losses. |
3-Level Smart BMSComprehensive protection: Level 1 — per-cell voltage/temp/IR across 45 modules; Level 2 — per-column SOC/SOH and fault isolation; Level 3 — rack-level inverter communication and safety interlock. Optional aerosol/perfluorohexanone FSS. | Maintenance-Free StorageUltra-low self-discharge rate enables up to 6 months of storage without maintenance charging — ideal for phased project deployments, seasonal sites, and spare-module inventory. No equalization, no water topping, zero scheduled maintenance. | Elite Energy Density314Ah high-capacity cells deliver superior Wh per kg and Wh per m² vs 280Ah alternatives — maximizing total system capacity within constrained indoor battery rooms and substation footprints. |
Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Model / Product Type | GHR-314 / High-Voltage 3-Stack DC Battery Rack |
| Application | Large C&I Hybrid Projects, Grid-Tied BESS, Microgrid, Peak Shaving, Backup Power | |
| DC Bus Voltage | Configurable up to 768Vdc+ (Module Series/Parallel Arrangement) | |
| Battery System | Cell Chemistry | LiFePO4 (LFP) Grade A — 3.2V / 314Ah Prismatic Cells |
| Max Energy per Rack | 241 kWh — 45 Modules (15 per Column × 3 Columns) | |
| Charge/Discharge Current | 157 A Continuous / 314 A Peak | |
| Cycle Life / DOD | ≥ 6,000 Cycles at 25°C, 0.5C, 90% DOD | |
| Management & Safety | Communication | CAN 2.0 / RS485 / RS232 — BMS-to-Inverter & BMS-to-EMS |
| BMS Architecture | 3-Level — Cell / Column / Rack with Safety Interlock | |
| Fire Suppression (FSS) | Optional Aerosol or Perfluorohexanone — Confirm with Order | |
| Physical | Module Weight | 125 kg per Module |
| Ingress Protection | IP20 — Indoor Rack Installation | |
| Warranty | System & Performance | 5 Years Standard / Scalable to 10 Years / 6,000 Cycles |
Table 1.0 — GHR-314 technical specifications. DC bus voltage, module count, and paralleling scheme confirmed per project. IEC 62619 cell certification. FSS selection and local fire code compliance confirmed with order.
Frequently Asked Questions
Q: How does the 3-stack architecture compare to a single-column rack?
The GHR-314's 3-column design arranges modules in three vertical stacks within one rack frame — achieving approximately 2–3× the energy density of a conventional single-column rack occupying the same floor area. A fully loaded GHR-314 holds 45 modules (241kWh) vs typically 12–15 modules (60–80kWh) in a single-column rack. For a 1 MWh installation: 4–5 GHR-314 racks vs 12–15 single-column racks — significant savings in floor space, DC cabling, and BMS coordination points.
Q: How is the DC bus voltage configured for my inverter?
The GHR-314's 3-column modular design allows custom series/parallel arrangements to match your inverter's DC input voltage window — up to 768Vdc+ per rack. This enables direct DC coupling without intermediate DC/DC converters, avoiding the 2–4% efficiency loss and added cost of conversion stages. Provide your inverter model and DC voltage range — E-Able Power engineering configures the module arrangement and validates compatibility within the technical proposal (2–3 business days). Multi-rack paralleling for higher capacity is also supported.
Q: What customization and scalability options does the GHR-314 support?
The GHR-314 is fully configurable. Options subject to project volume: module count per rack (up to 45), DC bus voltage configuration, communication protocol selection (CAN/RS485/RS232), fire suppression type (aerosol or perfluorohexanone), rack color and OEM labeling, and multi-rack paralleling for MWh-scale systems. Paralleling cables, DC combiner boxes, and system-level BMS coordination are designed per installation. 5-year warranty scalable to 10 years.
Q: What installation and maintenance requirements does the GHR-314 have?
Installation: indoor battery room with level floor (rated for ~5,700kg per fully loaded rack), adequate ventilation per local electrical code, and minimum 1m service clearance on all sides. DC cabling from rack to inverter location. Maintenance is near-zero — LFP cells require no water topping, no equalization charging, and no electrolyte replacement. Annual inspection: visual check of module connections, bolt torque verification, and BMS SoH data review. The 3-column design allows individual module replacement without rack disassembly. Remote commissioning support included; on-site engineer available for projects above 500 kWh.
Factory: Dongguan, Guangdong, China. Cells IEC 62619 certified. 5-year standard warranty, scalable to 10 years. Project-specific compliance documentation available on request.
Related Products
Explore Related Products
GHR-314 High-Voltage Battery Rack FAQ
Answers about the GHR-314 3-stack high-voltage battery rack — capacity, LFP cells, DC bus voltage, scalability, safety, installation and warranty.
1What is the capacity of the GHR-314 battery rack?
+
The GHR-314 delivers up to 241 kWh per rack from 15 modules per column across a 3-column stack (up to 45 modules, each ~16 kWh), giving high energy density in a compact footprint for commercial and industrial energy storage.
2What battery cells does the GHR-314 use?
+
It uses Grade A LFP (LiFePO4) cells rated 3.2V / 314Ah, delivering 6,000+ cycles at 25°C, 0.5C and 90% depth of discharge. LFP chemistry gives inherent thermal stability, long cycle life and maintenance-free operation.
3What DC bus voltage does the GHR-314 support?
+
The 3-column design supports a high-voltage DC bus up to 768V, configurable in series and parallel to match your inverter's DC input range while reducing current and copper losses.
4How does the 3-stack architecture compare to a single-column rack?
+
The 3-column design stacks three vertical columns in one rack frame, achieving higher energy density and a smaller floor footprint than a single-column rack while simplifying cabling, service access and thermal management.
5What control and communication does the GHR-314 support?
+
It integrates a 3-level smart BMS (cell / column / module) with communication over CAN 2.0, RS485 and RS232, monitoring voltage, current, temperature and fault protection.
6What installation and maintenance does the GHR-314 require?
+
Install it indoors on a level floor with adequate ventilation and load-rated rack mounting. Maintenance is limited to periodic BMS checks and terminal re-torque, with a 5-year warranty and flexible project configuration.
7Can the GHR-314 be scaled or customised for a project?
+
Yes. Module count per rack (up to 45), DC bus voltage and configuration are selectable per project volume and site requirement, so the GHR-314 can be sized for C&I peak shaving, microgrids, solar self-consumption or grid services.
Send your load profile, solar plan and project requirements for a source-backed technical proposal.
