MUSE Series Vandal-Proof Bollard Light
MUSE Series IK10 vandal-proof solar bollard light by E-Able Power.
View Product E-ABLE POWER — PRODUCT DATASHEET
COMMERCIAL SOLAR LIGHTING SOLUTIONS
CYLINDRICAL SERIES 8,000MAH / 3 HEIGHTS
Key Specifications at a Glance
| Models | ZC-CPD4104 / ZC-CPD2204 | Solar Panel | 5V / 4.5W Monocrystalline |
| Battery | 3.2V / 8,000mAh Grade A LiFePO4 | LED Array | 30 PCS High-Efficacy LED Chips |
| CCT | 3000K – 6500K Selectable | Charging Time | 3 – 5 Hours Direct Sunlight |
| Heights Available | 350mm / 650mm / 850mm | Canopy Diameter | Φ260mm |
| Pole Diameter | Φ150mm | Housing | Die-Casting Aluminum + PC |
| IP Rating | IP65 — Waterproof & Weather-Resistant | Certifications | CE / RoHS |
| Warranty | 5 Years Standard |
Fig 1.0: ZC-CPD4104/2204 — Cylindrical Solar Bollard Series (350mm, 650mm, 850mm Heights)
Engineering Excellence
High-Capacity 8,000mAh Storage
Robust 3.2V/8,000mAh Grade A LiFePO4 battery — paired with a 5V/4.5W monocrystalline panel for 3-5h rapid charging. Delivers consistent all-night illumination with multi-night autonomy during overcast periods. Over 2.5x the capacity of standard bollard batteries.
Three-Height Design Flexibility
Available in 350mm, 650mm, and 850mm heights — mix and match within a single project for layered, cohesive lighting compositions. Low-profile 350mm for flower bed borders, mid 650mm for general pathways, tall 850mm for main promenades and entry plazas.
Industrial-Grade Construction
Die-casting aluminum + impact-resistant PC — IP65 sealed against rain, dust, and corrosion. The Φ260mm canopy provides superior solar collection area and distinctive architectural presence. Engineered for high-traffic public and commercial environments.
Technical Specifications
| Specification | ZC-CPD4104 / ZC-CPD2204 |
|---|---|
| Housing Material | Die-Casting Aluminum + Impact-Resistant PC |
| Solar Panel | 5V / 4.5W — High-Efficiency Monocrystalline Silicon |
| Battery Capacity | 3.2V / 8,000mAh — Grade A LiFePO4 |
| LED Configuration | 30 PCS High-Efficacy LED Chips |
| Color Temperature | 3000K – 6500K (Selectable CCT) |
| Charging Time | 3 – 5 Hours — Standard Direct Sunlight |
| Canopy Diameter | Φ260mm |
| Pole Diameter | Φ150mm |
| Height Options | 350mm / 650mm / 850mm — Three Configurations Available |
| IP Rating | IP65 — Waterproof / Weather-Resistant |
| Installation | Surface-Mount / Stake-Down — Zero Trenching, Zero Wiring |
| Certifications | CE / RoHS |
Table 1.0 — ZC-CPD4104 & ZC-CPD2204 share identical electronics and construction; choose by height preference. Mix all three heights (350/650/850mm) within a single landscape project for layered, dynamic pathway illumination. 5-year standard warranty.
Ideal Landscape Applications
Corporate Campuses & Plazas Upscale Residential Borders Commercial Promenades Public Park Walkways
Frequently Asked Questions
Q: How do the three height options affect lighting performance and which should I choose?
All three heights share identical electronics — same 8,000mAh battery, 4.5W panel, and 30 LED array — so lighting output is consistent across options. The choice is purely architectural: 350mm for low-profile ground-level accents along flower beds and lawn borders; 650mm for standard pathway illumination at hip height — the most popular configuration for general walkways; 850mm for prominent entry plazas, main promenades, and areas where the bollard itself serves as a visible architectural element. Best practice: mix all three heights in a single project — tall at main entries, mid along connecting paths, low at garden perimeters — for a professional layered lighting composition.
Q: How does the 8,000mAh battery compare to standard bollard batteries?
The 3.2V/8,000mAh (25.6Wh) Grade A LiFePO4 battery provides over 2.5x the capacity of entry-level bollards (typically 3,000mAh). With a full charge from the 4.5W monocrystalline panel (3-5h sunlight), the fixture delivers 10-12 hours of continuous illumination — easily covering the longest winter nights. During 2-3 consecutive overcast days, the 8,000mAh reserve ensures reliable dusk-to-dawn operation where smaller batteries would deplete. The LiFePO4 chemistry also provides 2,000+ deep cycles, thermal stability above 270 deg C, and zero maintenance — no water, no electrolyte, no equalization required over the fixture's service life.
Q: Can the CPD4104/2204 be installed on different surfaces — concrete, soil, pavers?
Yes — zero-trench, zero-cable, zero-grid-connection installation works on any surface. Each bollard is fully self-contained with integrated solar panel, battery, LED, and optical sensor. For hard surfaces (concrete, pavers, stone): use expansion bolts through the base plate. For soft ground (soil, grass, gravel): use the included ground spike. The fixture auto-activates at dusk — no electrician, no permit, no ongoing electricity cost. Recommended spacing: 4-6 meters between units for continuous pathway coverage. The IP65 die-cast aluminum + PC housing eliminates rust and corrosion concerns across all surface types.
Q: What is the difference between ZC-CPD4104 and ZC-CPD2204 — and which markets are they for?
The two model numbers represent regional/market variants with identical core specifications — same 8,000mAh battery, 4.5W panel, 30 LED array, die-cast aluminum + PC construction, and 3-height options (350/650/850mm). Both carry the same Φ260mm canopy and Φ150mm pole profile. The dual SKU structure supports regional certification packaging and market-specific labeling — ideal for distributors serving multiple countries from a single supplier. For project specification, either model number is valid; confirm with your E-Able Power sales representative which SKU corresponds to your target market's certification preferences. Bulk OEM orders can be labeled per your requirements.
E-Able Power is an ISO 9001 & ISO 14001 certified manufacturer. All ZC-CPD4104/2204 bollards are CE and RoHS compliant with 5-year standard warranty.
Related Products
Explore Related Products
FAQ
Common questions.
1What sizes are available for CPD4104/2204?
+
Available dimensions: 350mm / 650mm / 850mm.
2What battery does the CPD4104/2204 use?
+
It uses 3.2V / 8,000mAh Grade A LiFePO4.
3Is the CPD4104/2204 weatherproof?
+
Yes — Die-Casting Aluminum + PC, rated IP65 — Waterproof & Weather-Resistant for outdoor use.
4What light output does the CPD4104/2204 offer?
+
3000K – 6500K Selectable light with 30 PCS High-Efficacy LED Chips.
5What powers the CPD4104/2204?
+
A 5V / 4.5W Monocrystalline solar panel charges the on-board battery.
6What certifications does the CPD4104/2204 carry?
+
CE / RoHS.
