View Product E-ABLE POWER — PRODUCT DATASHEET
COMMERCIAL SOLAR LIGHTING SOLUTIONS
DUAL-PROFILE SERIES 6,000MAH / ROUND & SQUARE
Key Specifications at a Glance
| Models | ZC-CPD3004 (Round) / ZC-CPD5004 (Square) | Housing | Die-Casting Aluminum + PC |
| Solar Panel | 5V/4.5W (CPD3004) / 5V/5W (CPD5004) | Battery | 3.2V / 6,000mAh Grade A LiFePO4 |
| LED | 20 PCS Ambient (CPD3004) / 80 PCS High-Vis (CPD5004) | CCT | 3000K – 6500K Selectable |
| Charging | 3 – 5 Hours Direct Sunlight | CPD3004 Dims | Φ230 × Φ150 × H300-800mm |
| CPD5004 Dims | 200 × 140 × H400-800mm | Height Options | 300 / 400 / 600 / 800mm |
| IP Rating | IP65 — Waterproof & Weather-Resistant | Certifications | CE / RoHS |
| Warranty | 5 Years Standard |
Fig 1.0: Round ZC-CPD3004 (Ambient 20 LED) vs Square ZC-CPD5004 (High-Visibility 80 LED)
Engineering Excellence
Round vs Square — True Design Choice
Not just cosmetic variants — real performance differentiation. CPD3004 (Round Φ230mm): 20 LED for soft ambient pathway glow. CPD5004 (Square 200×140mm): 80 LED — 4x the LED count for high-visibility zones. Deploy CPD3004 along garden paths, CPD5004 at main entries and road crossings — unified housing quality, purpose-matched output.
6,000mAh Mid-Capacity Sweet Spot
3.2V/6,000mAh (19.2Wh) Grade A LiFePO4 battery — double the capacity of entry-level 3,000mAh bollards. Paired with 4.5W-5W monocrystalline panels for 3-5h rapid charging. Delivers 10-12 hours of nightly illumination with reliable multi-night autonomy. The ideal balance of cost, capacity, and form factor for large-scale commercial deployments.
Four-Height Layering System
Unmatched height flexibility — 300, 400, 600, and 800mm across the series. CPD3004 available in all four heights; CPD5004 in 400-800mm range. Layered deployment strategy: 300mm for flower bed borders, 400mm for lawn edges, 600mm for pathway midpoints, 800mm for plaza entries — create a cohesive illumination gradient from a single product family.
Model Comparison & Technical Specifications
| Specification | ZC-CPD3004 (Round) | ZC-CPD5004 (Square) |
|---|---|---|
| Housing Material | Heavy-Duty Die-Casting Aluminum + Impact-Resistant PC | |
| Profile Shape | Round / Cylindrical | Square / Rectangular |
| Solar Panel | 5V / 4.5W Monocrystalline | 5V / 5W Monocrystalline |
| Battery Capacity | 3.2V / 6,000mAh (19.2Wh) — Grade A LiFePO4 | |
| LED Configuration | 20 PCS — Ambient Glow | 80 PCS — High-Visibility Output |
| Dimensions | Φ230 × Φ150 × H300-800mm | 200 × 140 × H400-800mm |
| Height Options | 300 / 400 / 600 / 800mm | 400 / 600 / 800mm |
| Charging Time | 3 – 5 Hours — Standard Direct Sunlight | |
| Color Temperature | 3000K (Warm) – 6500K (Task) — Selectable CCT | |
| IP Rating | IP65 — Waterproof / Weather-Resistant | |
| Installation | Surface-Mount / Stake-Down — Zero Trenching, Zero Wiring | |
| Certifications | CE / RoHS | |
Table 1.0 — ZC-CPD3004 vs ZC-CPD5004 comparison. Key differences: profile shape (Round vs Square), LED count (20 vs 80 PCS), panel output (4.5W vs 5W), and available heights. Same 6,000mAh battery, CCT range, charging time, and IP65 rating. Select CPD3004 for ambient garden/pathway glow; CPD5004 for high-visibility entries and road crossings. 5-year standard warranty on both models.
Ideal Landscape Applications
Corporate Plazas Residential Borders Public Park Walkways Commercial Promenades
Frequently Asked Questions
Q: How do I choose between CPD3004 (Round) and CPD5004 (Square) — is it just aesthetics?
The choice involves both aesthetics and lighting performance. ZC-CPD3004 (Round): 20 LED chips produce a soft ambient glow — ideal for garden pathways, residential borders, and areas where subtle wayfinding is preferred over brightness. ZC-CPD5004 (Square): 80 LED chips — 4x the LED count — deliver substantially higher visibility for main promenades, corporate plaza entries, road crossings, and high-traffic zones. Panel wattage also differs: 4.5W (CPD3004) vs 5W (CPD5004) for faster charge recovery. Best practice: use both in a single project — CPD5004 at main entries and high-traffic intersections, CPD3004 along secondary garden paths and lawn borders. The shared die-cast aluminum housing quality ensures visual cohesion across the mix.
Q: How should I use the four height options effectively in a landscape design?
The series offers 300, 400, 600, and 800mm heights — the widest range in E-Able's bollard catalog. Recommended layered deployment: 300mm — low-profile accents along flower beds, lawn perimeters, and intimate garden corners (CPD3004 only). 400mm — knee-height markers for residential borders and hotel garden paths (both models). 600mm — standard hip-height illumination for main commercial pathways and public park walkways (both models). 800mm — prominent architectural presence at plaza entries, corporate campus gates, and road crossing points (both models). This four-tier system creates a natural illumination gradient — taller/brighter at key decision points, lower/softer along connecting paths.
Q: Is the 6,000mAh battery sufficient for all four height and LED configurations?
Yes — the 3.2V/6,000mAh (19.2Wh) LiFePO4 battery is a well-matched mid-capacity sweet spot that serves both models. The 20-LED CPD3004 sips power for extended runtime; the 80-LED CPD5004 pairs its higher output with a 5W panel (vs 4.5W) for faster daily recharge to compensate. Both configurations deliver 10-12 hours of rated illumination from a full charge. During 2-3 consecutive overcast days, the 6,000mAh reserve provides reliable dusk-to-dawn autonomy. For projects in extreme-weather locations requiring deeper reserves, consider the CPD1106 (8,000mAh) or CPD3005 (8,000mAh) from E-Able Power's bollard range. The user-replaceable LiFePO4 battery supports 2,000+ deep cycles with zero maintenance.
Q: What installation and maintenance advantages does the dual-profile design offer?
Both models share the same zero-trench, zero-cable, zero-grid-connection installation philosophy. Surface-mount on hard surfaces (concrete, pavers) with expansion bolts; stake-down on soft ground (soil, grass) with included spike. The dual-profile design simplifies procurement — one supplier, one battery type, one warranty, one maintenance protocol, but two distinct visual and performance profiles for design flexibility. Annual maintenance: clean solar panel (glass cleaner + soft cloth), inspect die-cast aluminum housing for physical damage. IP65 sealing eliminates internal maintenance. 5-year standard warranty. For large-scale deployments, E-Able Power provides complimentary DIALux simulation with both round and square bollard fixtures modeled in the project file.
E-Able Power is an ISO 9001 & ISO 14001 certified manufacturer. All ZC-CPD3004/5004 bollards are CE and RoHS compliant with 5-year standard warranty.
Related Products
Explore Related Products
FAQ
Common questions.
1What sizes are available for CPD3004/5004?
+
Available dimensions: 300 / 400 / 600 / 800mm.
2What battery does the CPD3004/5004 use?
+
It uses 3.2V / 6,000mAh Grade A LiFePO4.
3Is the CPD3004/5004 weatherproof?
+
Yes — Die-Casting Aluminum + PC, rated IP65 — Waterproof & Weather-Resistant for outdoor use.
4What light output does the CPD3004/5004 offer?
+
3000K – 6500K Selectable light with 20 PCS Ambient (CPD3004) / 80 PCS High-Vis (CPD5004).
5What powers the CPD3004/5004?
+
A 5V/4.5W (CPD3004) / 5V/5W (CPD5004) solar panel charges the on-board battery.
6What certifications does the CPD3004/5004 carry?
+
CE / RoHS.
